0.91 Inch Monochrome White PMOLED Display Mod128×32 IIC SSD1306ule

Short Description:

0.91 inch PMOLED, 12832 OLED display, IIC OLED, SSD1306 display, monochrome white OLED, small OLED screen, Arduino OLED, wearable display, PMOLED module


  • Size: 0.91
  • Resolution: 128*32
  • Interface: IIC
  • Luminance (nits): 180
  • Viewing angle: ALL
  • Overall size: 38*12*3.8
  • Active Area: 22.384*5.584
  • IC: SSD1306
  • Remark: Monochrome White
down load to pdf

Product Details

Product Tags

This 0.91‑inch monochrome white PMOLED display module comes with 128*32 resolution, adopting IIC communication interface and SSD1306 driver IC. Ultra‑narrow strip‑shaped design saves plenty of space for compact equipment. It provides 180 nits brightness and excellent all‑viewing‑angle performance. OLED feature brings high contrast and clear white character & graphic output. Overall dimension is 38 × 12 × 3.8 mm, active display area 22.384 × 5.584 mm. Perfect for small‑size embedded projects such as IoT devices, wearable equipment, instrument indicator, smart home panel and Arduino / MCU secondary development. Samples are available, please contact us for datasheet and bulk price.


Size

Resolution
Interface
Luminance
(nits)
Viewing angle		 mm
Overall size		 mm
Active Area		IC
Remark
0.91
128*32IIC180ALL38*12*3.822.384*5.584SSD1306Monochrome White
0.96
128*64SPI/IIC180ALL27.3*27.8*4.121.744*10.864SSD1306Monochrome White
1.09
128*64SPI180ALL24*33*3.810.86*25.58CH1115Monochrome White
1.3
128*64IIC150ALL35.4*33.5*429.42*14.7SH1106Monochrome White
1.3
72*128SPI100ALL20*37*2.9511.07*16.69SSD1317/FT6336GMonochrome White
1.5
128*128SPI/IIC100ALL34*49.3*5026.855*26.855SH1107Monochrome White
1.54
128*64MCU/SPI/IIC120ALL42.04*27.22*1.4635.04*17.51SSD1309ZCMonochrome White
1.54
128*64MCU/SPI/IIC120ALL42.04*27.22*1.4535.05*17.52SSD1309Monochrome White
1.54
128*64MCU80ALL73.00*41.86*2.1561.41*30.69SSD1309Monochrome White
1.71
128*32IIC120ALL60.5*18.75*4.9542.218*10.538SSD1312Monochrome White
2.08
256*64IIC150ALL72.5*27.24*5.151.18*12.78SH1122Monochrome White
2.23
128*32SPI/IIC120ALL74*30*8.255.02*13.1SSD1305Monochrome White
2.42
128*64SPI/IIC120ALL72*43*755.01*27.49SSD1309Monochrome White
2.7
128*64MCU80ALL41.92*73.00*2.1461.41*30.69SSD1309Monochrome White
2.8
256*64MCU/SPI100ALL84.00*25.80*2.0071.104*19.264SSD1322UMonochrome White
2.8
256*64MCU/SPI100ALL175.93*43.87*4.9369.1*17.26SSD1322/FT6436UMonochrome White
3.12
256*64SPI80ALL102*35*6.676.78*19.18SSD1322Monochrome White
3.2
256*64MCU/SPI80ALL88.00*27.80*2.0076.78*19.18SSD1322UMonochrome Yellow
5.5
256*64SPI80ALL160.0*50.0*6.6135.65*33.89SSD1322Monochrome Green
