DC5521 Female Socket to TYPE-C Male Connector PD Fast Charging Chip

Minimum starting quantity is 1 piece, support small sample order!

Specifications: Power Rating Product Name Product Code / Model Electrical Performance (PD Chip Specifications) 100W DC Female to Type-C Male PD100W Chip Adapter 100W UL20AWG
Specifications: 140W DC Female to Type-C Male PD140W Chip Adapter 140W UL20AWG

Product Details

Power Rating	Product Name	Product Code / Model	Electrical Performance (PD Chip Specifications)
100W	DC Female to Type-C Male PD100W Chip Adapter	100W UL20AWG	Chip Protocol: USB-C Power Delivery (PD 3.0); Input: DC 5.5x2.1mm or 5.5x2.5mm (Female); Output: USB-C (Male); Max Power: 100W (20V/5A); Supported Voltages: 5V, 9V, 12V, 15V, 20V; Conductor Gauge: 20 AWG; Feature: Built-in PD trigger chip for automatic voltage negotiation
140W	DC Female to Type-C Male PD140W Chip Adapter	140W UL20AWG	Chip Protocol: USB-C Power Delivery (PD 3.1); Input: DC 5.5x2.1mm or 5.5x2.5mm (Female); Output: USB-C (Male); Max Power: 140W (28V/5A); Supported Voltages: 5V, 9V, 12V, 15V, 20V, 28V; Conductor Gauge: 20 AWG; Feature: Built-in PD trigger chip for automatic voltage negotiation (Supports EPR - Extended Power Range)
